NTS 370: 14-1/2" Semi-Automatic Double-Column Cold Saw (5-1/8" Round Tube Capacity)

13,800.00

$13,800 (PRE-ORDER)

Ready to place an order, or do you have any questions? Call us at (909)476-8007

The Quantum NTS 370 Semi-Automatic (Double-Column Style) Cold Saw has the capability of moving the head up to 45 degrees left and up to 60 degrees right. The reduction unit is in oil bath with a membrane pump for coolant and Incorporated Recirculating Mechanical Coolant System (Coolant Filter). The NTS 370 is equipped with an anti-burr device and bar stop. Service tools come with the machine, as well as the machine's manual and steel pedestal. This NTS 370 will be equipped with a 350mm Quantum Blade ($120 Value).

  • Weight: 1,100 lbs.
  • Max Vice Opening: 7-1/4"
  • Overall Dimensions: 104"W x 73"H x 47"L
  • 2 Speed Options: 25 R.P.M. and 50 R.P.M.
  • Blade Size Used: 370mm x 32mm x 2.5mm Thick
    (14.5" x 1.25" x 0.10" Thick)
Add To Cart

NTS 370 Specifications and Cutting Capacities:

  • Round Tube Cutting at 90°: 5-1/8"
  • Round Tube Cutting at 45° Left: 5-1/8"
  • Round Tube Cutting at 45° Right: 5-1/8"
  • Square Tube Cutting at 90°: 4-1/2"
  • Square Tube Cutting at 45° Left: 3-7/8"
  • Square Tube Cutting at 45° Right: 3-7/8"
  • Solid Round Cutting at 90°: 3-7/8"
  • Solid Round Cutting at 45° Left: 3-7/8"
  • Solid Round Cutting at 45° Right: 3-7/8"
  • Rectangular Tube Cutting at 90°: 3-7/8"H x 6-5/8"W
  • Rectangular Tube Cutting at 45° Left: 3-7/8"H x 5-1/2"W
  • Rectangular Tube Cutting at 45° Right: 3-7/8"H x 5-1/2"W

Operation (Cycle start is obtained by pressing the relevant double start button. The machine performs the following operations during the cutting cycle):

  1. Vice Closing and Activation of Blade Motor.
  2. Cutting Head Down-Stroke.
  3. Blade Motor Stop and Return of Head to Initial Position.
  4. Vice Opening.
  • Trigger Switch Operation.
  • Vice complete with Anti-Burr Device.
  • Reduction Unit in Oil Bath.
  • Comes complete with blade.
  • Swivel Head up to 60° Left & up to 45° Right.
  • Head Rotation Stops: 45° - 0° - 45° - 60°
  • Adjustable stops for Head Vertical Stroke.
  • Italian Made = Supreme Quality.
  • Double-Hinged Pin with Eccentric Bush.
  • Shave Breaker to keep the blade cleaned.
  • Motor Pump for Blade Lubrication.
  • Jet separation system to keep blade oiled.
  • Include Bar Stop, Service Tools and Manual.
  • Adjustable material stop for Repetitive Production.
