BM200 Mackma Non-Mandrel Tube & Pipe Rotary Bender (7.85" O.D. x 0.20" Round Tube Capacity)


BM200 Mackma Non-Mandrel Tube & Pipe Rotary Bender (7.85" O.D. x 0.20" Round Tube Capacity)

1,000,000.00

Ready to place an order, or do you have any questions?
Call us at (909) 476-8007

The BM200 is a part of the MACKMA BM Series Non-Mandrel Rotary Benders - this series of Non-Mandrel Rotary Benders are THE ONLY Non-Mandrel Pipe Bending Machine Series capable of bending tubes and pipes to the left or right, by means of a reversible die holder, thanks to their innovative design, which is patented by the Italian manufacturer, MACKMA. With the BM200, you have the ability of bending up to 7.85” O.D. Round Tube (200mm O.D.) and 0.20” / 5mm in wall thickness. The BM200 MACKMA Non-Mandrel Rotary Bender can bend parts as low as 3 times the O.D. (Outter Diameter) and a maximum bending CLR (Center Line Radius) of 35.4” / 900mm. All of the features bundled into these machines ensures for high-repeatability, efficiency and accuracy for even the most demanding of markets.

(Optional Tooling Available for Round Tube, Pipe, Square Tube, etc.)
(Shown with Optional Tooling.)

Click Here to Pre-Order

Maximum Bending Capacities:

  • Max Round Tube Outer Diameter: 8.6” O.D. (219.3mm)

  • Diameter using FE – 42 daN/mq: 6.6” x 0.430” (168.3 × 10.97mm)

  • Diameter using FE – 35 daN/mq: 8.6” x 0.250” (219.1 × 6.35mm)

  • Diameter using AISI 304/316 – 65 kg/mq: 6.6” x 0.270” (168.3 × 7.11mm)

Main Technical Data for the BM200:

  • Max Torque: 115,000 N/m

  • Maximum Radius: 43.3” (1,100mm)

  • Max Curvature Angle: 180°

  • Maximum Rotation Speed: 0.8 RPM

  • Bending Direction: Left-Hand and Right-Hand Directions

  • Voltages Available: 220 Volt / 3 Phase / 60Hz or 480 Volt / 3 Phase / 60Hz

  • Max Installed Power: 11 kW

  • Weight: 4,850 lbs. (2,200 kg.)

  • Dimensions (WxHxL): 47.2” x 53.1” x 72.8” (1,200 x 1,350 x 1,850mm)

  • Operating Temperature: 32–122°F (0–50°C)

  • Warranty on Defective Parts: 2 Years

Suitable for the Following Industries:

  • Technical and Industrial Items

  • Furniture

  • Automotive

  • Motorcycle and Boat

  • Sports and Wellness Items

  • And Many, Many More!!

The curvature axis is inverter controlled; therefore, the rotational speed ranges between 0.5 revs/min and 1 revs/min. This is also possible thanks to the potentiometer installed, which allows the operator to choose the rotational speed that best suits the pipe to be bended. The cantilever head allows the creation of complex figures, which require the pipe to pass under the head. The special shaft system allows the machine to be interfaced with the tools of competition machinery currently available on the market. The inverter controlled motor minimises power consumption. Mackma uses high quality Italian-made components, which ensure long durability (2-Year MACKMA Warranty).

New Generation



TOOL KITS ALSO AVAILABLE
