PC16: INDUSTRIAL END WROUGHT IRON MACHINE

6,895.00

Ready to place an order, or do you have any questions? Call us at (909) 476-8007

Electrical Options and Pricing:

  • 220V / 3PH / 60Hz - $6,895

  • 480V / 3PH / 60Hz - $6,895

  • 220V / 1PH / 60Hz - $7,295

The End Hot Wrought Machine QUANTUM NARGESA PC16, eases up the rolling job of hot steel. It rolls up the snail forged shaped end. This decorations are commonly used as extremes in scrolls and decorative parts.Gates, windows, fencing, metal furniture, etc...

  • Easy handling: Any worker is able to carry out this job, even without any previous preparation.

  • Readiness: Thousands of parts can be made in one working day.

  • Value and prestige: There are few craftsmen who can make these kinds of wrought jobs.

  • Sales: Possibility of selling parts with the forged extremes to different companies or steel stores.

    TECHNICAL FEATUERS

  • Adjustment of displacement or turns.

  • Adjustment of pressure according to material thickness.

  • Safety double command for the cycle drive.

  • Hydraulic clamp for the piece fastening.

  • Maximum capacity in round: 20mm

  • Maximum capacity in square: 20mm

  • Maximum capacity in flat bar: 50x10mm

  • Working speed: 45 mm/s

  • Return speed: 70 mm/s

  • Cycle time: 10 seconds

  • Pieces per minute: 4 pieces.

  • Engine power: 2,2 KW/ 3 CV (HP)

Click Here to Pre-Order





The End Hot Wrought Machine Nargesa PC16

eases up the rolling job of hot steel. It rolls up the snail forged shaped end. This decorations are commonly used as extremes in scrolls and decorative parts.Gates, windows, fencing, metal furniture, etc...
All Nargesa products are according to the CE regulations for the manufacturing of industrial machinery.




GOOD TEMPERATURE

In order to accomplish an optimum result at the different jobs, it is very important to have a good temperature in the piece to be shaped.
Forging furnaces Nargesa H1H2 and H3 are manufactured to reach these high temperatures for making a correct job.


DIMENSIONS OF THE MACHINE END HOT WROUGHT IRON MACHINE PC16

Machine Dimensions: 1350x620x1120 mm.

Weight: 310 Kg.

Tarif Code:  84622991

Other features:

  • Palletized bench to transport the machine easily to its working site or storage.

  • The machine is delivered completely assembled.


USES OF THE MACHINE: END HOT WROUGHT IRON MACHINE PC16

The Hot Wrought Machine Nargesa PC16, rolls up hot steel making a snail shaped extreme. It is used to create scrolls and designs for ornamental  forging in doors, windows, gates, metal furniture, etc...
