MT500A AUTOMATIC WROUGHT IRON TWISTING MACHINE


MT500A AUTOMATIC WROUGHT IRON TWISTING MACHINE

14,700.00

Ready to place an order, or do you have any questions? Call us at (909) 476-8007

Electrical Options and Pricing:

  • 220V / 3PH / 60Hz - $13,795

  • 480V / 3PH / 60Hz - $13,795

Automatic Wrought Iron machine QUANTUM NARGESA MT500A. It was patented by Prada Nargesa several years ago and this makes us be a leading company in manufacturing this kind of equipment. It has been manufactured in a welded and mechanized steel monoblock. It has been thought to work iron in cold. It's ideal for making all kinds of parts for the ornamental forging, balusters, scrolls, etc... Used in window grills, handrails, tables, chairs, doors, fences, windows etc.... Making a lot of different shapes in round, square and tubular profiles, flat bar, handrails, etc...

  • Working method by twisting and flexion in COLD.

  • Machine suitable for small and medium productions.

  • Safe and reliable transmission by a motor reducer with treated flat pinions, acomplishing a great performance with little maintenance.

  • Its perfect for making all kind of standard ornamental pieces and essential to make your own designs which are much more demanded in the market. The pieces as requested by architects, technicians and final users make it an indispensable tooling in a blacksmith workshop.

  • It's got two working sites, one for twisting and another one for bending with no neck limit. It means big sized pieced can be made, unlike in other machines of this kind in the market..

  • In order to make this kind of special jobs, Nargesa provides you under request either the tooling or the fitting discs so the very customer can create his own designs.

  • The forging equipment Nargesa MT500A is equipped with a set of tooling by means of which a great number of pieces can be made: Twisting, scrolls, hooks, chains...

  • There is also the possibility of purchasing optional tooling: Belly Top Railing, British Rail, Flat bent rings, ornamental baskets...

  • Possibility of buying the tooling for the machine in mm or inches.

  • CNC programmer to make high productions.

Add To Cart





TECHNICAL CHARACTERISTICS

  • Max. Twisting Capacity: 1-3/4" (40mm)
  • Max. Bending Capacity: 1" (25.4mm)
  • Max. Scrolling & Bending in Flat Bar: 2" x 3/8" (50mm x 10mm)
  • Max. Continued Scrolling Length: 63.7" (1,620mm)
  • Engine Power: 4kW / 5.5CV
  • Rotary Speed: 4 R.P.M.
  • Weight: 3,000 lbs.
  • Dimensions: 88" x 39" x 51"


MT500A Control Panel

The control panel of the scroll forming machine MT500A, is characterized by its simplicity and ease of use. It's got a high production capacity  that allows programming the starting point and the ending point  of the piece to be made.

  • Easy use.
  • Digital display.
  • Touch pad.
  • Piece counter.
  • Automatic unbolt
  • Capacity for 8 different memories.
  • Independent control panel.

INCLUDED ACCESORIES FOR FORGING TWISTING MACHINE MT500A

TOOLING FOR SPIRAL START DIAMETER 80MM
(INCLUDED)

Tooling to make the Spiral Start Diam. 80mm.png

Tooling made of treated steel F1140 to make the start of the spiral in flat bar, square or round max. 10mm thickness.

REF: 120-01-03-00115
VOLUTE EXTERNAL DIAMETER: 80mm.
MAX. CAPACITY: 40x8mm.

TOOLING FOR SPIRAL START DIAMETER 100MM
(INCLUDED)

Tooling for Spiral Start Diam. 100mm.png

Tooling made of treated steel F1140 to make the start of the spiral in flat bar, square or round, 16mm maximum thickness.

REF: 120-01-03-00116
VOLUTE EXTERNAL DIAMETER: 100mm.
MAX. CAPACITY:  40x10mm Max: 16mm.

TOOLING FOR SPIRAL START DIAMETER 180MM
(INCLUDED)

Tooling to make Spiral Start Diam. 180mm.png

Tooling made of treated steel F1140 to make the start  of the spiral in flat bar, square or round, max. 25mm thickness.

REF:120-01-03-000153
VOLUTE EXTERNAL DIEMETER: 180mm.
MAX CAPACITY:  50x10mm Max: 25mm.

SPIRAL TOOLING DIAMETER 120MM
(INCLUDED)

Spiral Tooling Diam. 120mm.png

Tooling made of treated steel F1140 to make the second operation of the spiral in flat bar, square or round max. 10mm thickness.

REF: 120-01-03-00117
SCROLL EXTERNAL DIAMETER: 120mm.
MAX. CAPACITY: 40x8mm

SPIRAL TOOLING DIAMETER 220MM
(
INCLUDED)

Spiral tooling Diam. 220mm.png

Tooling made of steel F1140 to make the second operation of the spiral in flat bar, square or round max 16mm thickness.

REF: 130-01-03-00172
SCROLL EXTERNAL DIAMETER: 220mm.
MAX. CAPACITY:  40x10mm Max: 16mm.

SPIRAL TOOLING DIAMETER 450MM
(
INCLUDED)

%0ASpiral Tooling Diam. 450mm.png

Tooling made of steel F1140 to make the second operation of the spiral in flat bar, square or round max. 25mm thickness.

REF:130-01-03-00171
SCROLL EXTERNAL DIAMETER: 450mm.
MAX. CAPACITY:  50x10mm Max: 25mm.

FLAT BEND RINGS 8MM
(INCLUDED)

Tooling made of steel F1140 to make rings with 80mm inner diameter either in round or square.

REF: 130-01-03-00010
RING INNER DIAMETER: 80mm.
 Max CAPACITY: round or square 16mm.
The spiral cuts and some rings could be obtained to be put between the balausters

FLAT BENDING RINGS, INNER DIAMETER 96,100,110MM
(INCLUDED)

%0ATooling for Hooks and Chains.png

Microfusion treated tooling to make all kind of bendings, hooks, chains. etc...

REF: 120-01-03-00007
Max. Capacity. round or square 20mm.*
Flat bar  50x10mm
It bends all kind of material

* For different diameters please ask the manufacturers

    FLAT BAR BENDING TOOLING
    (INCLUDED)

    Flat Bar Bending Tooling.png

    Tooling made of treated steel to make bending operations in flat bars, handrails or any kinds of clods.

    REF: 140-01-03-00011
    MAX. CAPACITY: Flat bar 50x10mm.
    Bending with minimum external radious.
    WEIGHT: 3,1 Kg.

    TOOLING TO MAKE SCROLLS ON SQUARE BARS 12 AND 35MM OR 1/4" AND 1 1/2" WHITWORTH
    (INCLUDED)

    Tooling made of treated steel  140 to make the scrolling on square bars 12x12mm and  35x35mm or 1/4x1/4" and 1 1/2"x1 1/2" Inches Whitworth, on conventional mild steel.

    UNITS PER MACHINE: 2
    REF: 120-01-03-00123 -----------(12x12mm and 35x35mm)
    REF: 125-01-03-00100 -----------(1/4x1/4" and 1 1/2"x1 1/2" Inches Whitworth)

    TOOLING TO TWIST SQUARE 14 AND 30MM 0R 3/8" OR 1 1/4" WHITWORTH
    (INCLUDED)

    Tooling to Twist square 14 and 30mm or 3:8%22 and 1 1:4%22 inch Whitwort.png

    Tooling made of treated steel F1140 to make twisting operations in square 14x14mm and 30x30mm or 3/8"x3/8" and 1 1/4"x1 1/4"" inches Whitworth, in Carbon coal.


    UNITS PER MACHINE: 2

    REF: 120-01-03-00124 -----------(14x14mm and  30x30mm)

    REF: 125-01-03-00101 -----------(3/8"x3/8" and 1 1/4"x1 1/4" inches Whitworth.

    TOOLING TO TWIST SQUARE 16 AND 25MM 0R 1" OR 1/2" WHITWORTH
    (INCLUDED)

    Tooling to twist square 16 and 25mm or 1%22 and 1:2%22 inches Whitwort.png

    Made of treated steel F1140 to make the twisting for 16x16mm square bar and 25x25mm or 1"x1" and 1/2"x1/2" inches Whitworth, in conventional carbon steel.

    UNITS PER MACHINE: 2
    REF: 120-01-03-00125 -----------(16x16mm and 25x25mm)

    REF: 125-01-03-00102 -----------(1"x1" and 1/2"x1/2" inches Whitwort).

    TOOLING TO SCROLL 18 and 20mm SQUARE BAR 3/4" and 5/8" WHITWORTH
    (INCLUDED)

    Tooling to scroll 18 and 20mm square bar or 3:4%22 and 5:8%22 inches Whitwort.png

    Made of treated steel F1140 to make twisting in 18x18mm and  20x20mm square bar or 3/4"x3/4" and 5/8x5/8" inches  Whitwort, in conventional carbon steel.



    UNITS PER MACHINE: 2
    REF: 120-01-03-00127 -----------(18x18mm and 20x20mm)
    REF: 125-01-03-00103 -----------(3/4x3/4" and 5/8x5/8" inches Whitworth)

    TOOLING FOR SCROLLING 40MM SQUARE AND FLAT BAR 50X10MM OR 1 3/4" AND 2"X 3/8" WHITWORTH
    (INCLUDED)

    Tooling for Scrolling 40mm square and Flat bar 50x10 mm or 1 3:4%22 and 2%22x3:8%22inches Whitwort.png

    Made of treated steel F1140 to make the scrolling in 40x40mm square bar and 50x10mm flat bar or 1 3/4"x1 3/4" and  2"x3/8" inches Whitwort, in conventional carbon steel.

    UNITS PER MACHINE: 2
    REF: 120-01-03-00126 -----------(40x40mm y 50x10mm)
    REF: 125-01-03-00104 -----------(1 3/4"x1 3/4" y 2"x3/8" inches Whitworth)

    BASKETS TOOLING
    (OPTIONAL)


    Tooling to make all kinds of ornamental baskets in different sizes in square or round.

    REF: 140-01-03-00012
    MAX. CAPACITY: 4 square or round bars of 12mm
    WEIGHT: 55Kg.

    Available tooling for millimeter and inch square sizes.


    OPTIONAL TOOLING FOR FORGING TWISTING MACHINE MT500A

    BELLY TOP RAIL TOOLING DIAMETER 225MM
    (OPTIONAL)

    Belly Top Railing Tooling Diam. 225mm.png

    To make the belly top railing styles, very used in balconies and windows.

    REF: 140-01-03-00003
    INNER DIAMETER: 225mm.
    MAX. CAPACITY: 16mm round or square.
    WEIGHT: 12 Kg.

    FLAT BEND RINGS, INNER DIAMETER 96,100,110MM
    (OPTIONAL)

    Flat bent rings, Inner Diam. 96,100,110mm.png

    Tooling made os steel to make bending operations in square and round bars and the so called British Rail.

    REF: 140-01-03-00005
    INNER DIAMETER: 96,100,110mm
    MAX. CAPACITY: 16mmRound or square.
    WEIGHT: 10 Kg.

    EDGE SCROLL TOOLING
    (OPTIONAL)

    Tooling made of treated  steel to make volutes or spirals on its edge  in order to give it a different aspect, very used in some specific countries.

    REF: 140-01-03-00006
    MAX. CAPACITY: Round or square 25mm.
    WEIGHT: 0,400 kg.

    OVAL SCROLL TOOLING
    (OPTIONAL)

    Tooling made of steel to make oval scrolls for all kinds of rails.

    UNITS PER TOOLING: 2
    REF: 140-01-03-00004
    EXTERNAL DIAMETER: 240x190mm.
    MAX. CAPACITY: 16 mm square or round
    WEIGHT: 11 Kg.

    BENT PIPE IN FIXE RADIUS
    (OPTIONAL)

    Tooling made of steel to make bents in adjustable and fixed radius and different degrees.

    REF: 140-01-03-00002
    PIPE MAX. DIAMETER: 40mm
    MINIMUM PIPE THICKNESS: 3mm
    RADIUS OF THE PIECE: 3 times the pipe diameter.
    DEGREES: Max. 180º
    WEIGHT: From 15 to 35 Kg.

    DOUBLE EYED TOOLING
    (OPTIONAL)

    Tooling to make the folding commonly called "pig's tail"it's very used in balconies, handrails and many ornamental utilities.

    PIECES PER TOOLING: 7
    REF: 140-01-03-00001
    DOUBLE EYE:  To the right , to the left and double.
    MX. CAPACITY: 16mm Round.
    WEIGHT: 35 kg.



    INFO FORGING TWISTING MACHINE MT500A

    The baskets tooling Nargesa, can be fit at any of our scroll makers MT150A or MT500A.

    Four square bars welded on their ends are placed on the tooling. Then make a twist to one side and after to the opposite direction. At this point the tooling pulls the piece and cotracts it, accomplishing a perfect finish.  The piece will have one shape or another, depending on the amount of turns.

    Available tooling for millimeter and inch square size


    MT500A- Dimensions.png

    DIMENSIONS OF THE MACHINE FORGING TWISTING MACHINE MT500A

    Dimensions of the machine: 2220x 980x1280 mm.

    Weight: 1350 Kg.

    Tariff Item Code:  84622998

    Other Features:

    • Palletized bench to  move the machine easily to the working site or storage.
    • The machine is delivered completely assembled.

    USES OF THE MACHINE: FORGING TWISTING MACHINE MT500A

    The Forging Automatic Scroll Bending Machine Nargesa MT500A  makes all kind of pieces for the ornamental forging, balausters, scrolls etc... Used in window grills, handrails, tables, chairs, windows, fences... Making a great deal of different shapes in square, round, tubular profiles, flat bar etc... It is an ideal machine for big productions. The main difference with the other ones is that it can work in all kind of big size materials.
