NTM 350-S: 14" Semi-Auto, Double-Column Cold Saw (4-5/8" Round Tube Capacity)
Includes Variable Speed Inverter and 1 Blade
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NTM 350-S Vertical Semi-Automatic Cold Saw has a moveable head that can move up to 45 degrees left and 60 degrees right; and the head also has rotation stops at 45° - 0° - 45° - 60°. The NTM 350-S has a vice that is complete with an anti-burr device, motor pump for blade lubrication, shave breaker to keep the blade clean. This unit is equipped with a a 1 meter long bar stop, 1 meter long bar support arm, and service tools, as well as the machine's manual and steel pedestal. Electrical: The NTM 350-S can be brought in at either 220 Volt / 3 Phase / 60Hz or 480 Volt / 3 Phase / 60Hz.
Includes Variable Speed Inverter and 1 Blade
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NTM 350-S Vertical Semi-Automatic Cold Saw has a moveable head that can move up to 45 degrees left and 60 degrees right; and the head also has rotation stops at 45° - 0° - 45° - 60°. The NTM 350-S has a vice that is complete with an anti-burr device, motor pump for blade lubrication, shave breaker to keep the blade clean. This unit is equipped with a a 1 meter long bar stop, 1 meter long bar support arm, and service tools, as well as the machine's manual and steel pedestal. Electrical: The NTM 350-S can be brought in at either 220 Volt / 3 Phase / 60Hz or 480 Volt / 3 Phase / 60Hz.
Includes Variable Speed Inverter and 1 Blade
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NTM 350-S Vertical Semi-Automatic Cold Saw has a moveable head that can move up to 45 degrees left and 60 degrees right; and the head also has rotation stops at 45° - 0° - 45° - 60°. The NTM 350-S has a vice that is complete with an anti-burr device, motor pump for blade lubrication, shave breaker to keep the blade clean. This unit is equipped with a a 1 meter long bar stop, 1 meter long bar support arm, and service tools, as well as the machine's manual and steel pedestal. Electrical: The NTM 350-S can be brought in at either 220 Volt / 3 Phase / 60Hz or 480 Volt / 3 Phase / 60Hz.
NTM 350-S COLD SAW CUTTING CAPACITIES:
Round Tube:
Straight Cut: 4-1/2" or 4.5"
45° Left Cut: 4-1/2" or 4.5"
45° Right Cut: 4-1/2" or 4.5"
60° Right Cut: 3-1/4" or 3.25"
Square Tube:
Straight Cut: 3-3/4" or 3.75"
45° Left Cut: 3-1/4" or 3.25"
45° Right Cut: 3-1/4" or 3.25"
60° Right Cut: 3-1/4" or 3.25"
Solid Round:
Straight Cut: 3-3/4" or 3.75"
45° Left Cut: 3-3/4" or 3.75"
45° Right Cut: 3-3/4" or 3.75"
60° Right Cut: 3-1/4" or 3.25"
Rectangular Tube:
Straight Cut: 3-1/4"H x 6-1/2"W or 3.25"H x 6.5"W
45° Left Cut: 3-1/4"H x 4-3/4"W or 3.25"H x 4.75"W
45° Right Cut: 3-1/4"H x 4-3/4"W or 3.25"H x 4.75"W
60° Right Cut: 3-1/4"H x 3-1/4"W or 3.25"H x 3.25"W
NTM 350-S COLD SAW SPECIFICATIONS:
Vertical Semi-Automatic Cold Saw has a moveable head that can move up to 45 degrees left to right and 60 degrees right.
Vice complete with anti-burr device.
Motor pump.
Chip breaker to keep the blade clean.
Adjustable stops for head vertical stroke.
Service tools.
Instruction manual and exploded view of spare parts.
Blade Size: 370 x 2.5 x 32mm Bore HSS Blade
Maximum Vice Opening: 7” (180mm)
Machine Weight: 1,059 lbs. (480 kg.)
Variable Speed Inverter: 36-72 R.P.M.
Overall Dimensions: 6'-6” H x 8'-9” W x 4' L or 79” H x 104” W x 48” L or 2,000 mm x 2,640 mm x 1,200 mm
Additionally, this Saw Includes: Instruction Manual, Service Tools & 1 HSS 370mm Cold Saw Blade.
Cycle start is obtained by pressing the relevant start pedal. The machine performs the following operations during the cutting cycle:
Closing of Vice & Activation of Blade Motor.
Cutting Head Begins Down-Stroke.
Completes Cut & Head Returns to Initial Position & Blade Motor Stops.
The Vice will then Open.
(REPEAT)
