NTS 370 COLD SAW CUTTING CAPACITIES:
Round Tube:
Straight Cut: 5"
45° Left Cut: 5"
45° Right Cut: 5"
Square Tube:
Straight Cut: 4-1/2" or 4.5"
45° Left Cut: 3-3/4" or 3.75"
45° Right Cut: 3-3/4" or 3.75"
Solid Round:
Straight Cut: 3-3/4" or 3.75"
45° Left Cut: 3-3/4" or 3.75"
45° Right Cut: 3-3/4" or 3.75"
Rectangular Tube:
Straight Cut: 3-3/4"H x 6-1/2"W or 3.75"H x 6.5"W
45° Left Cut: 3-3/4"H x 5-1/4"W or 3.75"H x 5.25"W
45° Right Cut: 3-3/4"H x 5-1/4"W or 3.75"H x 5.25"W
NTS 370 COLD SAW SPECIFICATIONS:
Vertical Semi-Automatic Cold Saw has a moveable head that can move up to 45 degrees left to right.
Vice complete with anti-burr device.
Motor pump.
Chip breaker to keep the blade clean.
Adjustable stops for head vertical stroke.
Service tools.
Instruction manual and exploded view of spare parts.
Blade Size: 370 x 2.5 x 32mm Bore HSS Blade
Maximum Vice Opening: 7.2” (185mm)
Machine Weight: 1,100 lbs. (500 kg.)
Variable Speed Inverter: 25 - 50 R.P.M.
Overall Dimensions: 6'-1” H x 8'-9” W x 4' L or 73” H x 104” W x 48” L or 1,854 mm x 2,640 mm x 1,200 mm
Additionally, this Saw Includes: Instruction Manual, Service Tools & 1 HSS 370mm Cold Saw Blade.
Cycle start is obtained by pressing the relevant start pedal. The machine performs the following operations during the cutting cycle:
Closing of Vice & Activation of Blade Motor.
Cutting Head Begins Down-Stroke.
Completes Cut & Head Returns to Initial Position & Blade Motor Stops.
The Vice will then Open.
(REPEAT)
